FD-H001 Anti-Corrosion Coating: Epoxy Zinc Primer for Chemical Industry Safety

Name: FD-H001 Anti-Corrosion Coating: Epoxy Zinc Primer for Chemical Industry Safety
SKU: MIC-TGyRAMacsVre

FD-H001 two-component epoxy primer for steel substrates. Supplied in liquid form.

Reference price (FOB)

US $2-10 / kg

Quantity	Reference price
100-999 kg	USD 10.00 / kg
1,000-999,999 kg	USD 6.00 / kg
1,000,000+ kg	USD 2.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings Primers

Product specifications

Model NO.: FD-H001
Color: Grey
Appearance: Liquid
Main Raw Material: Epoxy
Method: Spray
Level: Primer
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Luster: Matt
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:80um Dry Film: 40um
After Sales Service: 5 Years
Trademark: Signal
Transport Package: Barrel Package in Pallet
Specification: 35*30
Origin: Dongying China
HS Code: 3208100000
Customization: Available
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Lead Time: 7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components: Two-component
Proportion: About 2.40
Dry Time: 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio: 10:1
Coating thickness: Wet film:80um Dry film: 40um
Construction methord: High pressure airless spray, air spray, brush, roller
Shelf life: 12 months

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

Product Description

Product Name: Superior Anti-Corrosion Coating: Epoxy Zinc Primer for Chemical Industry Safety

FD-H001 Anti-Corrosion Coating: Epoxy Zinc Primer for Chemical Industry Safety
1.Introduction:

Epoxyzinc_-richprimerisatwo_-componentcoatingwithepoxy resinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Highshielding property, superioranti-rustproperty, strongadhesion, and good oilandwaterresistance.

Number of components	Two-component
Color	Grey
Proportion	About 2.40
Dry Time	23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio	10:1
Coating thickness	Wet film:80um Dry film: 40um
Construction methord	High pressure airless spray, air spray, brush, roller
Shelf life	12 months

2.Surface treatment:
The steel surface is meticulously prepared through shot blasting or sand blasting to achieve Sa2.5 level, or manually cleaned to St3 level for optimal performance.

3.Construction conditions:
The substrate temperature must exceed the dew point by 3°C, with relative humidity maintained under 85%, and wind force not exceeding level 3. If the substrate temperature falls below 5°C, the reaction between the epoxy resin and curing agent ceases, necessitating a halt in construction activities. Outdoor work should avoid rainy, foggy, windy, and sandy conditions, as well as morning and evening condensation.

4.Notes:
1. Prior to application, ensure thorough mechanical stirring of component A, then blend it uniformly with component B.
2. Maintain regular stirring during the application process to prevent sedimentation, which could disrupt the powder-to-liquid ratio and compromise the paint film's quality.
3. Aim for a dry film thickness of at least 70μm, typically achieved through 1 to 2 coats.
4. Once mixed, the two-component paint should ideally be used within a 5-hour window. Prolonged exposure may degrade the coating's integrity.
5. Seal the curing agent tightly after use to prevent undesirable reactions with ambient water vapor, which could lead to losses.
