FD-H001 Dual Component Epoxy Coating with Matt Finish

Name: FD-H001 Dual Component Epoxy Coating with Matt Finish
SKU: MIC-StqUHXvClopb

FD-H001 two-component epoxy anti-corrosion coating for steel substrates.

Reference price (FOB)

US $2-10 / kg

Quantity	Reference price
100-999 kg	USD 10.00 / kg
1,000-999,999 kg	USD 6.00 / kg
1,000,000+ kg	USD 2.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings

Product specifications

Model NO.: FD-H001
Main Raw Material: Epoxy
Method: Spray
Level: Primer
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Luster: Matt
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:80um Dry Film: 40um
After Sales Service: 5 Years
Transport Package: Barrel Package in Pallet
Specification: 35*30
Trademark: signal
Origin: Dongying China
HS Code: 3208100000
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Lead Time: 7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components: Two-component
Color: Grey
Proportion: About 2.40
Dry Time: 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio: 10:1
Coating thickness: Wet film:80um Dry film: 40um
Construction methord: High pressure airless spray, air spray, brush, roller
Shelf life: 12 months

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

Product Description

Product Name: Factory Price Double Component Epoxy Anti Corrosive Primer Coating

1.Introduction:

Epoxyzinc_-richprimerisatwo_-componentcoatingwithepoxy resinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Highshielding property, superioranti-rustproperty, strongadhesion, and good oilandwaterresistance.

Number of components	Two-component
Color	Grey
Proportion	About 2.40
Dry Time	23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio	10:1
Coating thickness	Wet film:80um Dry film: 40um
Construction methord	High pressure airless spray, air spray, brush, roller
Shelf life	12 months

2.Surface treatment:
The steel surface is meticulously shot blasted or sand blasted to Sa2.5 level, or manually rust-removed to St3 level, ensuring optimal adhesion.

3.Construction conditions:
The substrate temperature must be 3°C above the dew point with a relative humidity under 85%, and wind force not exceeding level 3. If the substrate temperature drops below 5°C, the reaction between epoxy resin and curing agent halts, necessitating a pause in construction. Avoid construction in adverse weather like rainy, foggy, or windy days, or during early and late-day condensation.

4.Notes:
1. Before use, ensure thorough mechanical stirring of component A for uniformity, followed by mixing with component B.
2. Regular stirring during the coating process is vital to prevent sedimentation, which could skew the powder-to-liquid ratio, compromising the paint film quality.
3. Recommended dry film thickness is ≥70μm, accomplished over 1 to 2 coats for best results.
4. Use the mixed two-component paint within 5 hours to maintain coating quality; exceeding this timeframe could degrade performance.
5. Once the curing agent is depleted, seal it tightly and use promptly to avert losses from reactions with atmospheric moisture.
