Model: FD-H001

FD-H001 Durable Matt Zinc Rich Epoxy Paint

FD-H001 two-component epoxy anti-corrosion coating for steel substrates.

Reference price (FOB)

US $2.5-6.5 / kg

QuantityReference price
100-999 kgUSD 6.50 / kg
1,000-999,999 kgUSD 4.50 / kg
1,000,000+ kgUSD 2.50 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

Product specifications

Model NO.
FD-H001
Main Raw Material
Epoxy
Method
Spray
Level
Primer
Drying Method
Air Drying
Substrate
Steel
Components
Film Forming Matter
Formation Mechanism
Conversion Type
Luster
Matt
Weight
20kg/Barrel
Construction Method
High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness
Wet Film:80um Dry Film: 40um
After Sales Service
5 Years
Transport Package
Barrel Package in Pallet
Specification
35*30
Trademark
Singal
Origin
Dongying China
HS Code
3208100000
Production Capacity
50000ton/Year
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg
Lead Time
7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components
Two-component
Color
Grey
Proportion
About 2.40
Dry Time
23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio
10:1
Coating thickness
Wet film:80um Dry film: 40um
Construction methord
High pressure airless spray, air spray, brush, roller
Shelf life
12 months

Packaging & shipping

Transport Package
Barrel Package in Pallet
Specification
35*30
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg

Product description

Product Description

Product Name: Zinc Rich Epoxy Primer Sewage Plant Metal Protection Anti Corrosive Paint

1.Introduction:

Epoxyzinc-richprimerisatwo-componentcoatingwithepoxy resinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Highshielding property, providing superioranti-rustcapabilities, strongadhesion, and excellent oilandwaterresistance.
Number of components Two-component
Color Grey
Proportion About 2.40
Dry Time 23±2°C   Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio 10:1
Coating thickness Wet film:80um   Dry film: 40um
Construction methord High pressure airless spray, air spray, brush, roller
Shelf life 12 months

2.Surface treatment:
The steel surface should be prepared by shot blasting or sand blasting to Sa2.5 level, or manually cleaned to St3 level for optimal application.

3.Construction conditions:
Ensure the substrate temperature is at least 3°C above the dew point, with relative humidity <85%, and wind force ≤ level 3. If the substrate temperature drops below 5°C, the reaction between epoxy resin and curing agent halts, and application should cease. Avoid construction during rainy, foggy, windy, or sandy conditions and during times of morning and evening dew for best results.

4.Notes:
1. Prior to application, use mechanical stirring to thoroughly mix component A, then combine it evenly with component B.
2. Stir regularly during application to prevent sedimentation, which could disrupt the balance between powder and liquid, potentially compromising the paint film's quality.
3. It is advisable that the dry film thickness measures ≥70μm, achieved with 1 to 2 coats.
4. After components are mixed, the paint should be used within 5 hours to maintain quality, as extended time may affect the coating's effectiveness.
5. Once the curing agent is depleted, ensure the container is sealed tightly and used promptly to prevent any reaction with atmospheric moisture, which could lead to losses.
