FD-H001 Epoxy Coating - Matt Luster, 20kg, Suitable for Air Spray Application

Name: FD-H001 Epoxy Coating - Matt Luster, 20kg, Suitable for Air Spray Application
SKU: MIC-DferjdKuZqpA

FD-H001 two-component epoxy anti-corrosion coating for steel substrates.

Reference price (FOB)

US $2-10 / kg

Quantity	Reference price
100-999 kg	USD 10.00 / kg
1,000-999,999 kg	USD 6.00 / kg
1,000,000+ kg	USD 2.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings

Product specifications

Model NO.: FD-H001
Main Raw Material: Epoxy
Method: Spray
Level: Primer
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Luster: Matt
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:80um Dry Film: 40um
After Sales Service: 5 Years
Transport Package: Barrel Package in Pallet
Specification: 35*30
Trademark: signal
Origin: Dongying China
HS Code: 3208100000
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Lead Time: 7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components: Two-component
Color: Grey
Proportion: About 2.40
Dry Time: 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio: 10:1
Coating thickness: Wet film:80um Dry film: 40um
Construction methord: High pressure airless spray, air spray, brush, roller
Shelf life: 12 months

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

Product Description

Product Name: Factory Price Double Component Epoxy Anti-Corrosive Primer Coating

1. Introduction:

Epoxyzinc_-richprimerisatwo_-componentcoatingwithepoxy resinasthebasematerial, phosphorousironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Highshielding property, superioranti-rustproperty, strongadhesion, and excellent oilandwaterresistance.

Number of components	Two-component
Color	Grey
Proportion	About 2.40
Dry Time	23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio	10:1
Coating thickness	Wet film:80um Dry film: 40um
Construction methord	High pressure airless spray, air spray, brush, roller
Shelf life	12 months

2. Surface treatment:
The steel surface is meticulously prepared, either shot blasted or sandblasted to a pristine Sa2.5 level, or manually cleaned to achieve a thorough St3 level rust removal.

3. Construction conditions:
The substrate temperature must consistently be 3°C above the dew point, with relative humidity maintained below 85%, and wind force not exceeding level 3. If the substrate temperature falls below 5°C, the epoxy resin and curing agent will cease to react, necessitating a halt in construction. Outdoor projects should avoid rainy, foggy, windy, or sandy days and steer clear of morning and evening condensation.

4. Notes:
1. Prior to use, ensure component A is thoroughly mixed with mechanical stirring, then blend it evenly with component B for optimal results.
2. During the coating process, maintain regular stirring to avert sedimentation, which could disrupt the powder-to-liquid ratio, potentially compromising the quality of the paint film.
3. The recommended dry film thickness should be at least 70μm, with 1 to 2 coats applied for best outcomes.
4. Once mixed, the two-component paint should ideally be used within 5 hours. Exceeding this time frame may degrade the quality of the coating.
5. Ensure the curing agent container is tightly sealed after use to prevent unwanted reactions with atmospheric moisture, which could lead to material loss.
