FD-H001 Epoxy Coating - Perfect for High Pressure Airless Spray

Name: FD-H001 Epoxy Coating - Perfect for High Pressure Airless Spray
SKU: MIC-LfqrNGhOCMYk

FD-H001 two-component epoxy anti-corrosion coating for steel substrates.

Reference price (FOB)

US $2-10 / kg

Quantity	Reference price
100-999 kg	USD 10.00 / kg
1,000-999,999 kg	USD 6.00 / kg
1,000,000+ kg	USD 2.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings

Product specifications

Model NO.: FD-H001
Main Raw Material: Epoxy
Method: Spray
Level: Primer
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Luster: Matt
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:80um Dry Film: 40um
After Sales Service: 5 Years
Transport Package: Barrel Package in Pallet
Specification: 35*30
Trademark: signal
Origin: Dongying China
HS Code: 3208100000
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Lead Time: 7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components: Two-component
Color: Grey
Proportion: About 2.40
Dry Time: 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio: 10:1
Coating thickness: Wet film:80um Dry film: 40um
Construction methord: High pressure airless spray, air spray, brush, roller
Shelf life: 12 months

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

Product Description

Product Name: Factory Price Double Component Epoxy Anti-Corrosive Primer Coating

1.Introduction:

Epoxyzinc_-richprimerisatwo_-componentcoatingwithepoxy resinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Highshielding property, superioranti-rustproperty, strongadhesion, and good oilandwaterresistance.

Number of components	Two-component
Color	Grey
Proportion	About 2.40
Dry Time	23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio	10:1
Coating thickness	Wet film:80um Dry film: 40um
Construction methord	High pressure airless spray, air spray, brush, roller
Shelf life	12 months

2.Surface treatment:
The steel surface is meticulously prepared using shot blasting or sand blasting to achieve an Sa2.5 level, or manually rust-removed to St3 level, ensuring optimal adhesion and performance.

3.Construction conditions:
To ensure the best results, the substrate temperature must exceed the dew point by 3°C, with relative humidity maintained below 85% and wind force not exceeding level 3. Construction should be halted if the temperature falls below 5°C, as the epoxy resin and curing agent will not react. Avoid unfavorable weather conditions such as rain, fog, wind, sand, and morning or evening condensation for outdoor applications.

4.Notes:
1. Before application, component A should be mechanically stirred thoroughly, then mixed uniformly with component B to ensure consistency.
2. It is crucial to regularly stir during the coating process to prevent sedimentation, which could disrupt the powder to liquid ratio and potentially compromise the integrity of the paint film.
3. The recommended dry film thickness is at least 70μm, achieved through 1 to 2 coats for optimal protection.
4. Once mixed, the two-component paint should ideally be used within 5 hours, as extended exposure may degrade the coating quality.
5. After using the curing agent, ensure it is sealed tightly and utilized promptly to prevent any loss due to reactions with atmospheric water vapor.
