FD-H001 Epoxy Coating - Suitable for Brush and Roll

Name: FD-H001 Epoxy Coating - Suitable for Brush and Roll
SKU: MIC-SfYRcruUOepB

FD-H001 two-component epoxy anti-corrosion coating for steel substrates.

Reference price (FOB)

US $2-10 / kg

Quantity	Reference price
100-999 kg	USD 10.00 / kg
1,000-999,999 kg	USD 6.00 / kg
1,000,000+ kg	USD 2.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings

Product specifications

Model NO.: FD-H001
Main Raw Material: Epoxy
Method: Spray
Level: Primer
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Luster: Matt
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:80um Dry Film: 40um
After Sales Service: 5 Years
Transport Package: Barrel Package in Pallet
Specification: 35*30
Trademark: signal
Origin: Dongying China
HS Code: 3208100000
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Lead Time: 7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components: Two-component
Color: Grey
Proportion: About 2.40
Dry Time: 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio: 10:1
Coating thickness: Wet film:80um Dry film: 40um
Construction methord: High pressure airless spray, air spray, brush, roller
Shelf life: 12 months

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

Product Description

Product Name: Factory Price Double Component Epoxy Anti-Corrosive Primer Coating

1. Introduction:

Epoxy zinc _-rich primer is a two _-component coating with epoxy resin as the base material, enhanced with phosphor iron powder, rust-proof pigment, etc., and solidified by polyamide. It is offered in a dual-component system A and B. Characteristics:Boasting high shielding properties, superior anti-rust capabilities, strong adhesion, along with excellent oil and water resistance.

Number of components	Two-component
Color	Grey
Proportion	About 2.40
Dry Time	23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio	10:1
Coating thickness	Wet film:80um Dry film: 40um
Construction methord	High pressure airless spray, air spray, brush, roller
Shelf life	12 months

2. Surface Treatment:
The steel surface must be meticulously shot blasted or sand blasted to a pristine Sa2.5 level, or carefully rust-removed to St3 level.

3. Construction Conditions:
Ensure the substrate temperature surpasses the dew point by at least 3°C, with humidity levels staying under 85%, and wind forces not exceeding level 3. Construction is to be paused when substrate temperatures drop below 5°C, as the epoxy resin and curing agent cease their reactions. Avoid operating on rainy, foggy, windy, sandy days, and during times of condensation, such as mornings and evenings, for outdoor projects.

4. Notes:
1. Prior to use, mechanically stir component A until it is thoroughly mixed, then combine it evenly with component B for optimal results.
2. During the coating procedure, remember to stir periodically to avert sedimentation, which can disrupt the powder to liquid balance, thereby impacting the paint film's quality.
3. It is advisable for the dry film thickness to be at least 70μm, with 1 to 2 coats applied for best effect.
4. Once mixed, the two-component paint should be utilized within 5 hours to maintain coating integrity; exceeding this duration may compromise quality.
5. After using the curing agent, seal it tightly and consume promptly to avert any spoilage due to reactions with moisture in the air.
