Model: FD-H001
FD-H001 Epoxy Paint Primer for Coverage
FD-H001 two-component epoxy primer for steel substrates.
Reference price (FOB)
US $4-10 / kg
| Quantity | Reference price |
|---|---|
| 100-9,999 kg | USD 10.00 / kg |
| 10,000-999,999 kg | USD 8.00 / kg |
| 1,000,000+ kg | USD 4.00 / kg |
Minimum order: 100 kg
Confirm the specification, quantity and shipping terms for your quotation.
Request a QuoteProduct specifications
- Model NO.
- FD-H001
- Main Raw Material
- Epoxy
- Method
- Spray
- Level
- Primer
- Drying Method
- Air Drying
- Substrate
- Steel
- Components
- Film Forming Matter
- Formation Mechanism
- Conversion Type
- Luster
- Matt
- Weight
- 20kg/Barrel
- Construction Method
- High Pressure Airless Spray, Air Spray, Brush, Rol
- Coating Thickness
- Wet Film:80um Dry Film: 40um
- After Sales Service
- 5 Years
- Transport Package
- Barrel Package in Pallet
- Specification
- 35*30
- Trademark
- signal
- Origin
- Dongying China
- HS Code
- 3208100000
- Production Capacity
- 50000ton/Year
- Package Size
- 30.00cm * 30.00cm * 35.00cm
- Package Gross Weight
- 20.000kg
- Lead Time
- 7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
- Number of components
- Two-component
- Color
- Grey
- Proportion
- About 2.40
- Dry Time
- 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
- Mixing ratio
- 10:1
- Coating thickness
- Wet film:80um Dry film: 40um
- Construction methord
- High pressure airless spray, air spray, brush, roller
- Shelf life
- 12 months
Packaging & shipping
- Transport Package
- Barrel Package in Pallet
- Specification
- 35*30
- Package Size
- 30.00cm * 30.00cm * 35.00cm
- Package Gross Weight
- 20.000kg
Product description
Product Description
Product Name: Steel Structure Anti-Corrosion Epoxy Zinc Rich Primer Paint
1. Introduction: Experience the pinnacle of protective coatings with our expertly formulated epoxy zinc rich primer. This two-component wonder incorporates cutting-edge technology to deliver unmatched protection for steel surfaces.
| Number of components | Two-component |
| Color | Grey |
| Proportion | About 2.40 |
| Dry Time | 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days |
| Mixing ratio | 10:1 |
| Coating thickness | Wet film:80um Dry film: 40um |
| Construction methord | High pressure airless spray, air spray, brush, roller |
| Shelf life | 12 months |
2. Surface treatment: Achieve optimal results with a meticulously prepared surface. Steel surfaces should be shot or sand blasted to Sa2.5 level, or manually rust-removed to St3 level for maximum primer adhesion.
The steel surface is shot blasted or sand blasted to Sa2.5 level, or manually rust-removed to St3 level.
3. Construction conditions: Ensure construction excellence by maintaining substrate temperatures 3°C above the dew point with humidity under 85% and wind force no greater than level 3. Construction in temperatures below 5°C should be postponed to prevent reaction halts. Avoid adverse weather conditions to maintain optimal coating quality.
The substrate temperature must be 3°C higher than the dew point, relative humidity <85%, wind force ≤ level 3; when the substrate temperature is lower than 5°C, the epoxy resin and curing agent stop reacting and construction should be stopped. Avoid rainy, foggy, windy and sandy days and condensation in the morning and evening for outdoor construction.
4. Notes: Enhance your application quality with these crucial guidelines.
1. Prior to application, ensure thorough mechanical stirring of component A before combining with component B for a seamless blend.
2. Maintain consistent stirring during application to avoid sedimentation, ensuring a balanced powder to liquid ratio for a flawless paint film.
3. Aim for a dry film thickness of ≥70μm, completing 1 to 2 coats for optimal coverage.
4. Utilize the mixed two-component paint within 5 hours to preserve its superior quality.
5. Securely seal the curing agent after use to prevent moisture reactions, optimizing longevity and minimizing waste.
