Model: FD-H001

FD-H001 Epoxy Paint Primer for Coverage

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $4-10 / kg

QuantityReference price
100-9,999 kgUSD 10.00 / kg
10,000-999,999 kgUSD 8.00 / kg
1,000,000+ kgUSD 4.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

Product specifications

Model NO.
FD-H001
Main Raw Material
Epoxy
Method
Spray
Level
Primer
Drying Method
Air Drying
Substrate
Steel
Components
Film Forming Matter
Formation Mechanism
Conversion Type
Luster
Matt
Weight
20kg/Barrel
Construction Method
High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness
Wet Film:80um Dry Film: 40um
After Sales Service
5 Years
Transport Package
Barrel Package in Pallet
Specification
35*30
Trademark
signal
Origin
Dongying China
HS Code
3208100000
Production Capacity
50000ton/Year
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg
Lead Time
7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components
Two-component
Color
Grey
Proportion
About 2.40
Dry Time
23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio
10:1
Coating thickness
Wet film:80um Dry film: 40um
Construction methord
High pressure airless spray, air spray, brush, roller
Shelf life
12 months

Packaging & shipping

Transport Package
Barrel Package in Pallet
Specification
35*30
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg

Product description

Product Description

Product Name: Steel Structure Anti-Corrosion Epoxy Zinc Rich Primer Paint

1. Introduction: Experience the pinnacle of protective coatings with our expertly formulated epoxy zinc rich primer. This two-component wonder incorporates cutting-edge technology to deliver unmatched protection for steel surfaces.

Epoxyzinc-richprimerisatwo-componentcoatingwithepoxy resinasthebasematerial, meticulously blended with phosphor iron powder, rust-proof pigment, and other premium ingredients, then expertly cured by polyamide. phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispackaged by dual componentsAand B, offering superior protection and ease of application.Characteristics: Revel in high shielding capabilities, unparalleled anti-rust properties, robust adhesion, and exceptional resistance to oil and water. This primer is engineered for excellence, combining advanced features to offer a formidable defense against corrosion.Highshielding property, superioranti-rustproperty, strongadhesion, and good oilandwaterresistance.
Number of components Two-component
Color Grey
Proportion About 2.40
Dry Time 23±2°C   Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio 10:1
Coating thickness Wet film:80um   Dry film: 40um
Construction methord High pressure airless spray, air spray, brush, roller
Shelf life 12 months

2. Surface treatment: Achieve optimal results with a meticulously prepared surface. Steel surfaces should be shot or sand blasted to Sa2.5 level, or manually rust-removed to St3 level for maximum primer adhesion.
The steel surface is shot blasted or sand blasted to Sa2.5 level, or manually rust-removed to St3 level.

3. Construction conditions: Ensure construction excellence by maintaining substrate temperatures 3°C above the dew point with humidity under 85% and wind force no greater than level 3. Construction in temperatures below 5°C should be postponed to prevent reaction halts. Avoid adverse weather conditions to maintain optimal coating quality.
The substrate temperature must be 3°C higher than the dew point, relative humidity <85%, wind force ≤ level 3; when the substrate temperature is lower than 5°C, the epoxy resin and curing agent stop reacting and construction should be stopped. Avoid rainy, foggy, windy and sandy days and condensation in the morning and evening for outdoor construction.

4. Notes: Enhance your application quality with these crucial guidelines.
1. Prior to application, ensure thorough mechanical stirring of component A before combining with component B for a seamless blend.
2. Maintain consistent stirring during application to avoid sedimentation, ensuring a balanced powder to liquid ratio for a flawless paint film.
3. Aim for a dry film thickness of ≥70μm, completing 1 to 2 coats for optimal coverage.
4. Utilize the mixed two-component paint within 5 hours to preserve its superior quality.
5. Securely seal the curing agent after use to prevent moisture reactions, optimizing longevity and minimizing waste.
