Model: FD-H001

FD-H001 Epoxy Primer Coating for High Pressure Airless Spray

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $4-10 / kg

QuantityReference price
100-9,999 kgUSD 10.00 / kg
10,000-999,999 kgUSD 8.00 / kg
1,000,000+ kgUSD 4.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

Product specifications

Model NO.
FD-H001
Main Raw Material
Epoxy
Method
Spray
Level
Primer
Drying Method
Air Drying
Substrate
Steel
Components
Film Forming Matter
Formation Mechanism
Conversion Type
Luster
Matt
Weight
20kg/Barrel
Construction Method
High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness
Wet Film:80um Dry Film: 40um
After Sales Service
5 Years
Transport Package
Barrel Package in Pallet
Specification
35*30
Trademark
signal
Origin
Dongying China
HS Code
3208100000
Production Capacity
50000ton/Year
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg
Lead Time
7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components
Two-component
Color
Grey
Proportion
About 2.40
Dry Time
23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio
10:1
Coating thickness
Wet film:80um Dry film: 40um
Construction methord
High pressure airless spray, air spray, brush, roller
Shelf life
12 months

Packaging & shipping

Transport Package
Barrel Package in Pallet
Specification
35*30
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg

Product description

Product Description

Product Name: Hot Sales High-Performance Anti-Rust Zinc Epoxy Primer for Steel Buildings

FD-H001 Epoxy Primer Coating for High Pressure Airless Spray
1.Introduction:

Epoxyzinc-richprimerisatwo-componentcoatingwithepoxy resinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Highshielding property, superioranti-rustproperty, strongadhesion, and good oilandwaterresistance.
Number of components Two-component
Color Grey
Proportion About 2.40
Dry Time 23±2°C   Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio 10:1
Coating thickness Wet film:80um   Dry film: 40um
Construction methord High pressure airless spray, air spray, brush, roller
Shelf life 12 months

2.Surface treatment:
The steel surface is expertly shot blasted or sand blasted to an impeccable Sa2.5 level, or professionally rust-removed to a pristine St3 level.

3.Construction conditions:
For optimal performance, ensure the substrate temperature is always 3°C above the dew point with a relative humidity below 85%, and wind force no greater than level 3. Should the substrate dip below 5°C, the reaction between the epoxy resin and curing agent ceases, necessitating a halt in construction. Avoid days with rain, fog, strong winds, and sandstorms, as well as morning and evening condensation, for any outdoor application.

4.Notes:
1. Prior to application, thoroughly mix component A using mechanical stirring, then blend evenly with component B for a flawless finish.
2. Consistent stirring throughout the coating process is crucial to prevent sedimentation, ensuring a balanced powder-to-liquid ratio and maintaining the high quality of the paint film.
3. For best results, aim for a dry film thickness of at least 70μm, completing 1 to 2 coats to achieve an optimal protective layer.
4. Once mixed, the two-component paint should ideally be used within 5 hours to preserve coating quality, as exceeding this timeframe may compromise the finish.
5. After utilizing the curing agent, ensure it is tightly sealed and used promptly to prevent unfavorable reactions with atmospheric water vapor, safeguarding against potential losses.

FD-H001 Epoxy Primer Coating for High Pressure Airless Spray
FD-H001 Epoxy Primer Coating for High Pressure Airless Spray
