FD-H001 Epoxy Zinc Rich Primer for Steel Structures

Name: FD-H001 Epoxy Zinc Rich Primer for Steel Structures
SKU: MIC-zTgruCjOhqUm

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $4-10 / kg

Quantity	Reference price
100-9,999 kg	USD 10.00 / kg
10,000-999,999 kg	USD 8.00 / kg
1,000,000+ kg	USD 4.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings Primers

Product specifications

Model NO.: FD-H001
Main Raw Material: Epoxy
Method: Spray
Level: Primer
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Luster: Matt
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:80um Dry Film: 40um
After Sales Service: 5 Years
Transport Package: Barrel Package in Pallet
Specification: 35*30
Trademark: signal
Origin: Dongying China
HS Code: 3208100000
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Lead Time: 7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components: Two-component
Color: Grey
Proportion: About 2.40
Dry Time: 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio: 10:1
Coating thickness: Wet film:80um Dry film: 40um
Construction methord: High pressure airless spray, air spray, brush, roller
Shelf life: 12 months

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

Product Description

Product Name: Steel Structure Anti-Corrosion Epoxy Zinc Rich Primer Paint

1.Introduction:

Epoxyzinc_-richprimerisatwo_-componentcoatingwithepoxy resinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:With high shielding properties, our primer delivers superiorshielding capability, unparalleledanti-ruststrength, formidableadhesion, and excellent oilandwaterresistance.

Number of components	Two-component
Color	Grey
Proportion	About 2.40
Dry Time	23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio	10:1
Coating thickness	Wet film:80um Dry film: 40um
Construction methord	High pressure airless spray, air spray, brush, roller
Shelf life	12 months

2.Surface treatment:
Prepare the steel surface meticulously by shot blasting or sand blasting to Sa2.5 level, or achieve manual rust-removal to St3 level for optimal results.

3.Construction conditions:
Ensure the substrate temperature is at least 3°C above the dew point with relative humidity under 85% and wind force at or below level 3. If substrate temperatures drop below 5°C, the epoxy resin and curing agent cease to react, thus halting construction. Avoid days with rain, fog, strong winds, or sand, and prevent condensation during early mornings or late evenings when working outdoors.

4.Notes:
1. Begin by mechanically stirring component A until it's evenly mixed, followed by a thorough blend with component B.
2. Maintain regular stirring throughout the coating process to avert sedimentation, which can disrupt the powder to liquid ratio, compromising the paint film quality.
3. Aim for a dry film thickness of no less than 70μm and complete 1 to 2 coats for best protection.
4. Post-mixing, utilize the two-component paint within 5 hours to ensure optimal coating quality.
5. Securely seal the curing agent after use and consume promptly to avoid losses from reactions with moisture in the air.
