FD-H001 Epoxy Zinc Rich Primer Paint for Surface Protection

Name: FD-H001 Epoxy Zinc Rich Primer Paint for Surface Protection
SKU: MIC-gaNUTOJvYerL

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $4-10 / kg

Quantity	Reference price
100-9,999 kg	USD 10.00 / kg
10,000-999,999 kg	USD 8.00 / kg
1,000,000+ kg	USD 4.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings Primers

Product specifications

Model NO.: FD-H001
Main Raw Material: Epoxy
Method: Spray
Level: Primer
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Luster: Matt
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:80um Dry Film: 40um
After Sales Service: 5 Years
Transport Package: Barrel Package in Pallet
Specification: 35*30
Trademark: signal
Origin: Dongying China
HS Code: 3208100000
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Lead Time: 7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components: Two-component
Color: Grey
Proportion: About 2.40
Dry Time: 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio: 10:1
Coating thickness: Wet film:80um Dry film: 40um
Construction methord: High pressure airless spray, air spray, brush, roller
Shelf life: 12 months

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

Product Description

Product Name: Steel Structure Anti-Corrosion Epoxy Zinc Rich Primer Paint

1.Introduction:

Epoxyzinc_-richprimerisatwo_-componentcoatingwithepoxyresinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Highshielding property, superioranti-rustproperty, strongadhesion, and good oilandwaterresistance.

Number of components	Two-component
Color	Grey
Proportion	About 2.40
Dry Time	23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio	10:1
Coating thickness	Wet film:80um Dry film: 40um
Construction methord	High pressure airless spray, air spray, brush, roller
Shelf life	12 months

2.Surface treatment:
The steel surface is meticulously shot blasted or sand blasted to achieve Sa2.5 level, ensuring the highest quality, or manually rust-removed to St3 level for superior priming.

3.Construction conditions:
The substrate temperature must exceed the dew point by 3°C. Maintain relative humidity below 85%, with wind force at a maximum of level 3. If the substrate temperature falls below 5°C, the epoxy resin and curing agent cease to react, halting the construction process. Avoid undertaking construction on rainy, foggy, windy, or sandy days, and steer clear of morning and evening condensation for outdoor projects.

4.Notes:
1. Ensure thorough mechanical stirring of component A before use, followed by an even mix with component B for optimal performance.
2. Stir regularly during the coating process to prevent sedimentation, as this imbalance in the powder-to-liquid ratio can undermine the quality of the paint film.
3. For best results, the recommended dry film thickness is ≥70μm, achieved through 1 to 2 coats.
4. The combined two-component paint should be used within 5 hours to maintain coating quality; exceeding this timeframe may compromise the finish.
5. After utilizing the curing agent, seal it tightly and use it promptly to avoid losses caused by reaction with ambient water vapor.
