FD-H001 Epoxy Zinc Rich Primer Paint: Ideal for All Construction Methods

Name: FD-H001 Epoxy Zinc Rich Primer Paint: Ideal for All Construction Methods
SKU: MIC-VAjRGPQHVMYL

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $4-10 / kg

Quantity	Reference price
100-9,999 kg	USD 10.00 / kg
10,000-999,999 kg	USD 8.00 / kg
1,000,000+ kg	USD 4.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings Primers

Product specifications

Model NO.: FD-H001
Main Raw Material: Epoxy
Method: Spray
Level: Primer
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Luster: Matt
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:80um Dry Film: 40um
After Sales Service: 5 Years
Transport Package: Barrel Package in Pallet
Specification: 35*30
Trademark: signal
Origin: Dongying China
HS Code: 3208100000
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Lead Time: 7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components: Two-component
Color: Grey
Proportion: About 2.40
Dry Time: 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio: 10:1
Coating thickness: Wet film:80um Dry film: 40um
Construction methord: High pressure airless spray, air spray, brush, roller
Shelf life: 12 months

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

Product Description

Product Name: Steel Structure Anti-Corrosion Epoxy Zinc Rich Primer Paint

1.Introduction:

Epoxyzinc_-richprimerisatwo_-componentcoatingwithepoxyresinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:This coating boasts a high shielding property, offering unrivaledanti-corrosion qualities, and exceptionalrust resistance.Its strongadhesion ensures the integrity of the coating over time, while its impressive oilandwaterresistance makes it a reliable choice for challenging environments.

Number of components	Two-component
Color	Grey
Proportion	About 2.40
Dry Time	23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio	10:1
Coating thickness	Wet film:80um Dry film: 40um
Construction methord	High pressure airless spray, air spray, brush, roller
Shelf life	12 months

2.Surface treatment:
To ensure peak performance, the steel surface should be meticulously prepared, either by shot blasting or sand blasting to Sa2.5 level, or by manual rust-removal to St3 level.

3.Construction conditions:
Construction is optimal when the substrate temperature exceeds the dew point by at least 3°C, with relative humidity maintained below 85%, and wind force at or below level 3. If the substrate temperature drops below 5°C, the reaction between the epoxy resin and curing agent halts, necessitating a suspension of construction. Avoid outdoor application in adverse weather conditions such as rain, fog, high winds, or sandstorms, as well as during condensation-prone morning and evening hours.

4.Notes:
1. Ensure thorough mixing of component A with mechanical stirring before blending evenly with component B to achieve optimal coating performance.
2. Maintain consistent stirring throughout the application to prevent sedimentation, which could disrupt the powder-to-liquid balance and compromise the coating quality.
3. For best results, aim for a dry film thickness of ≥70μm, applying 1 to 2 coats as needed.
4. The mixed two-component paint should be utilized within 5 hours to prevent degradation of the coating quality.
5. Once the curing agent is opened, secure it tightly and use promptly to prevent degradation from moisture exposure.
