Model: FD-H001

FD-H001 Epoxy Zinc Rich Primer Paint: Ideal for High Pressure Airless Spray

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $4-10 / kg

QuantityReference price
100-9,999 kgUSD 10.00 / kg
10,000-999,999 kgUSD 8.00 / kg
1,000,000+ kgUSD 4.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

Product specifications

Model NO.
FD-H001
Main Raw Material
Epoxy
Method
Spray
Level
Primer
Drying Method
Air Drying
Substrate
Steel
Components
Film Forming Matter
Formation Mechanism
Conversion Type
Luster
Matt
Weight
20kg/Barrel
Construction Method
High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness
Wet Film:80um Dry Film: 40um
After Sales Service
5 Years
Transport Package
Barrel Package in Pallet
Specification
35*30
Trademark
signal
Origin
Dongying China
HS Code
3208100000
Production Capacity
50000ton/Year
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg
Lead Time
7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components
Two-component
Color
Grey
Proportion
About 2.40
Dry Time
23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio
10:1
Coating thickness
Wet film:80um Dry film: 40um
Construction methord
High pressure airless spray, air spray, brush, roller
Shelf life
12 months

Packaging & shipping

Transport Package
Barrel Package in Pallet
Specification
35*30
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg

Product description

Product Description

Product Name: Steel Structure Anti-Corrosion Epoxy Zinc Rich Primer Paint

1.Introduction:

Epoxyzinc-richprimerisatwo-componentcoatingwithepoxyresinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Highshielding property, superioranti-rustproperty, strongadhesion, and good oilandwaterresistance.
Number of components Two-component
Color Grey
Proportion About 2.40
Dry Time 23±2°C   Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio 10:1
Coating thickness Wet film:80um   Dry film: 40um
Construction methord High pressure airless spray, air spray, brush, roller
Shelf life 12 months

2.Surface treatment:
The steel surface is expertly prepared through shot blasting or sand blasting to an immaculate Sa2.5 level, or meticulously de-rusted manually to achieve St3 level.

3.Construction conditions:
For optimal application, ensure the substrate temperature is at least 3°C above the dew point. Maintain relative humidity below 85% and wind force at or below level 3. If the substrate temperature falls below 5°C, the reaction between epoxy resin and curing agent ceases; thus, halt construction. Avoid adverse weather conditions such as rain, fog, high winds, and consider the risk of condensation during the early and late hours for outdoor applications.

4.Notes:
1. Prior to use, thoroughly stir component A using mechanical methods to achieve a uniform mixture before blending with component B.
2. Consistently stir during application to avert sedimentation, which can disrupt the powder-liquid balance and compromise the integrity of the paint film.
3. It is advisable to aim for a dry film thickness of at least 70μm, completing 1 to 2 coats for best results.
4. Post-mixing, the two-component paint should ideally be utilized within a 5-hour window. Exceeding this time frame may adversely affect the coating quality.
5. Once the curing agent is depleted, ensure it is sealed promptly and consumed quickly to prevent degradation from atmospheric moisture interactions.
