Model: FD-H001

FD-H001 Fast-Drying Matt Epoxy Primer Coating - Perfect for Quick Turnarounds

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $4-10 / kg

QuantityReference price
100-9,999 kgUSD 10.00 / kg
10,000-999,999 kgUSD 8.00 / kg
1,000,000+ kgUSD 4.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

Product specifications

Model NO.
FD-H001
Main Raw Material
Epoxy
Method
Spray
Level
Primer
Drying Method
Air Drying
Substrate
Steel
Components
Film Forming Matter
Formation Mechanism
Conversion Type
Luster
Matt
Weight
20kg/Barrel
Construction Method
High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness
Wet Film:80um Dry Film: 40um
After Sales Service
5 Years
Transport Package
Barrel Package in Pallet
Specification
35*30
Trademark
signal
Origin
Dongying China
HS Code
3208100000
Production Capacity
50000ton/Year
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg
Lead Time
7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components
Two-component
Color
Grey
Proportion
About 2.40
Dry Time
23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio
10:1
Coating thickness
Wet film:80um Dry film: 40um
Construction methord
High pressure airless spray, air spray, brush, roller
Shelf life
12 months

Packaging & shipping

Transport Package
Barrel Package in Pallet
Specification
35*30
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg

Product description

Product Description

Product Name: Hot Sales High-Performance Anti Rust Zinc Epoxy Primer for Steel Buildings

FD-H001 Fast-Drying Matt Epoxy Primer Coating - Perfect for Quick Turnarounds
1.Introduction:

Epoxyzinc-richprimerisatwo-componentcoatingwithepoxyresinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Highshielding property, superioranti-rustproperty, strongadhesion, and good oilandwaterresistance.
Number of components Two-component
Color Grey
Proportion About 2.40
Dry Time 23±2°C   Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio 10:1
Coating thickness Wet film:80um   Dry film: 40um
Construction methord High pressure airless spray, air spray, brush, roller
Shelf life 12 months

2.Surface treatment:
The steel surface is meticulously shot blasted or sand blasted to achieve a pristine Sa2.5 level, or manually treated to reach the St3 level of rust removal.

3.Construction conditions:
The substrate temperature must consistently be 3°C higher than the dew point, with relative humidity maintained below 85%, and wind force not exceeding level 3. When the substrate temperature drops below 5°C, the reaction between the epoxy resin and curing agent halts, necessitating a halt in construction. It is crucial to avoid rainy, foggy, windy, and sandy conditions, alongside preventing condensation in the morning and evening during outdoor applications.

4.Notes:
1. Before applying, ensure thorough mechanical stirring of component A for a homogeneous mix before combining it evenly with component B.
2. Consistently stir during the application process to avert sedimentation, which could disrupt the powder-to-liquid ratio and potentially compromise the quality of the paint film.
3. For optimal results, the dry film thickness should be ≥70μm, with 1 to 2 coats applied.
4. Once mixed, the two-component paint should preferably be used within 5 hours to avoid any adverse effects on coating quality.
5. After the curing agent is consumed, ensure it is securely covered and utilized promptly to prevent losses resulting from reactions with atmospheric water vapor.
