Model: FD-H001

FD-H001 High Coverage Matt Epoxy Primer Coating

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $4-10 / kg

QuantityReference price
100-9,999 kgUSD 10.00 / kg
10,000-999,999 kgUSD 8.00 / kg
1,000,000+ kgUSD 4.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

Product specifications

Model NO.
FD-H001
Main Raw Material
Epoxy
Method
Spray
Level
Primer
Drying Method
Air Drying
Substrate
Steel
Components
Film Forming Matter
Formation Mechanism
Conversion Type
Luster
Matt
Weight
20kg/Barrel
Construction Method
High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness
Wet Film:80um Dry Film: 40um
After Sales Service
5 Years
Transport Package
Barrel Package in Pallet
Specification
35*30
Trademark
signal
Origin
Dongying China
HS Code
3208100000
Production Capacity
50000ton/Year
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg
Lead Time
7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components
Two-component
Color
Grey
Proportion
About 2.40
Dry Time
23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio
10:1
Coating thickness
Wet film:80um Dry film: 40um
Construction methord
High pressure airless spray, air spray, brush, roller
Shelf life
12 months

Packaging & shipping

Transport Package
Barrel Package in Pallet
Specification
35*30
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg

Product description

Product Description

Product Name: Hot Sales High-Performance Anti Rust Zinc Epoxy Primer for Steel Buildings

FD-H001 High Coverage Matt Epoxy Primer Coating
1.Introduction:

Epoxyzinc-richprimerisatwo-componentcoatingwithepoxy resinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Highshielding property, superioranti-rustproperty, strongadhesion, and excellent oilandwaterresistance.
Number of components Two-component
Color Grey
Proportion About 2.40
Dry Time 23±2°C   Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio 10:1
Coating thickness Wet film:80um   Dry film: 40um
Construction methord High pressure airless spray, air spray, brush, roller
Shelf life 12 months

2.Surface treatment:
The steel surface should be meticulously shot blasted or sand blasted to Sa2.5 grade or manually rust-removed to St3 grade for optimal preparation.

3.Construction conditions:
Ensure the substrate temperature is consistently 3°C above the dew point with a relative humidity below 85%, and wind force not exceeding level 3. Construction must cease when substrate temperatures drop below 5°C, as the epoxy resin and curing agent will not react efficiently. Avoid construction during inclement weather conditions such as rain, fog, strong winds, and sandstorms, as well as high condensation periods in the mornings and evenings for any outdoor projects.

4.Notes:
1. Initiate use by thoroughly mixing component A using mechanical stirring, followed by equally thorough mixing with component B.
2. Continuous stirring during the application process is crucial to prevent sedimentation, which might lead to an imbalanced powder to liquid ratio thus compromising the final paint film quality.
3. For best results, aim for a dry film thickness of at least 70μm, completing 1 to 2 coats accordingly.
4. Upon mixing, it's imperative that the two-component paint is utilized within a 5-hour window to maintain superior coating quality.
5. Once the curing agent is depleted, ensure the container is tightly sealed and use the remaining contents promptly to prevent adverse reactions with moisture in the air, which could lead to unnecessary losses.
