FD-H001 High-Performance Epoxy Coating System for Steel Corrosion Resistance

Name: FD-H001 High-Performance Epoxy Coating System for Steel Corrosion Resistance
SKU: MIC-AGXpFtwWXbrl

FD-H001 two-component epoxy anti-corrosion coating for steel substrates. Supplied in liquid form.

Reference price (FOB)

US $4-10 / kg

Quantity	Reference price
100-9,999 kg	USD 10.00 / kg
10,000-999,999 kg	USD 8.00 / kg
1,000,000+ kg	USD 4.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings

Product specifications

Model NO.: FD-H001
Color: Grey
Appearance: Liquid
Main Raw Material: Epoxy
Method: Spray
Level: Primer
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Luster: Matt
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:80um Dry Film: 40um
After Sales Service: 5 Years
Trademark: signal
Transport Package: Barrel Package in Pallet
Specification: 35*30
Origin: Dongying China
HS Code: 3208100000
Customization: Available
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Lead Time: 7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components: Two-component
Proportion: About 2.40
Dry Time: 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio: 10:1
Coating thickness: Wet film:80um Dry film: 40um
Construction methord: High pressure airless spray, air spray, brush, roller
Shelf life: 12 months

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

Product Description

Product Name: Steel Structure Anti-Corrosion Epoxy Zinc Rich Primer Paint

1.Introduction:

Our EpoxyZinc_-RichPrimerisaninnovative two_-componentcoating solutionfeaturingepoxy resinasitscorematerial, complemented by phosphorironpowder, and fortified withrust-proofpigment. Enhanced withadvanced components, it is effectively cured by polyamide.This premium coating ispackaged in dual componentsAand B, ensuring optimal performance.Characteristics:Boasting highshielding properties, unparalleled anti-rust capabilities, robustadhesion, and excellent resistance tooilandwater,this paint is engineered for durability and protection.

Number of components	Two-component
Color	Grey
Proportion	About 2.40
Dry Time	23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio	10:1
Coating thickness	Wet film:80um Dry film: 40um
Construction methord	High pressure airless spray, air spray, brush, roller
Shelf life	12 months

2.Surface treatment:
Ensure the steel surface is meticulously prepared by shot blasting or sand blasting to Sa2.5 level, or manually clean to St3 level for maximum adhesion.

3.Construction conditions:
Maintain substrate temperature at least 3°C above dew point, with relative humidity below 85%, and wind force not exceeding level 3. If the substrate temperature drops below 5°C, halt construction as the epoxy resin's reaction with the curing agent stops. Avoid construction during adverse weather conditions such as rain, fog, strong winds, and sandy conditions. Avoid morning and evening condensation for best results.

4.Notes:
1. Prior to application, thoroughly mix component A using mechanical stirring before combining with component B for a homogeneous blend.
2. Maintain regular stirring throughout the coating process to prevent sedimentation, ensuring the powder to liquid ratio remains balanced for optimal paint film quality.
3. For best results, aim for a dry film thickness of ≥70μm, applying 1 to 2 coats as necessary.
4. Use the mixed two-component paint within 5 hours to avoid compromising the coating quality.
5. After using the curing agent, seal it tightly and use promptly to prevent loss from reactions with atmospheric moisture.
