FD-H001 High-Performance Epoxy Zinc Primer: Anti-Corrosion Coating for Chemical Plant Safety and Durability

Name: FD-H001 High-Performance Epoxy Zinc Primer: Anti-Corrosion Coating for Chemical Plant Safety and Durability
SKU: MIC-aGtpvhCMherq

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $2-10 / kg

Quantity	Reference price
100-999 kg	USD 10.00 / kg
1,000-999,999 kg	USD 6.00 / kg
1,000,000+ kg	USD 2.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings Primers

Product specifications

Model NO.: FD-H001
Main Raw Material: Epoxy
Method: Spray
Level: Primer
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Luster: Matt
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:80um Dry Film: 40um
After Sales Service: 5 Years
Transport Package: Barrel Package in Pallet
Specification: 35*30
Trademark: Signal
Origin: Dongying China
HS Code: 3208100000
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Lead Time: 7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components: Two-component
Color: Grey
Proportion: About 2.40
Dry Time: 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio: 10:1
Coating thickness: Wet film:80um Dry film: 40um
Construction methord: High pressure airless spray, air spray, brush, roller
Shelf life: 12 months

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

Product Description

Product Name: High-Performance Epoxy Zinc Primer: Anti-Corrosion Coating for Chemical Plant Safety and Durability

1. Introduction:

Epoxyzinc_-richprimerisatwo_-componentcoatingwithepoxy resinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Highshielding property, superioranti-rustfeature, strongadhesion, and excellent oilandwaterresistance.

Number of components	Two-component
Color	Grey
Proportion	About 2.40
Dry Time	23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio	10:1
Coating thickness	Wet film:80um Dry film: 40um
Construction methord	High pressure airless spray, air spray, brush, roller
Shelf life	12 months

2. Surface treatment:
The steel surface is meticulously shot blasted or sandblasted to Sa2.5 level, or manually rust-removed to the St3 level.

3. Construction conditions:
The substrate temperature must be 3°C above the dew point, relative humidity below 85%, wind force not exceeding level 3. If the substrate temperature falls below 5°C, the epoxy resin and curing agent cease to react, necessitating a halt in construction. Avoid adverse weather conditions such as rain, fog, strong winds, sandstorms, and condensation during morning and evening outdoor applications.

4. Notes:
1. Prior to use, employ mechanical stirring to homogenize component A, then blend it thoroughly with component B.
2. Stir the mixture regularly during application to avoid sedimentation, which could disturb the powder-to-liquid ratio and compromise the quality of the paint film.
3. It is advised that the dry film thickness should be at least 70μm, with 1 to 2 coats applied.
4. After mixing, the two-component paint should ideally be utilized within 5 hours. Exceeding this period may adversely affect coating quality.
5. Once the curing agent is depleted, seal it tightly and consume it promptly to prevent losses due to reactions with ambient water vapor.
