FD-H001 High-Performance Epoxy Zinc Primer: Corrosion Protection for Chemical Facilities

Model: FD-H001

FD-H001 High-Performance Epoxy Zinc Primer: Corrosion Protection for Chemical Facilities

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $2-10 / kg

QuantityReference price
100-999 kgUSD 10.00 / kg
1,000-999,999 kgUSD 6.00 / kg
1,000,000+ kgUSD 2.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote
CategoriesAnti-Corrosion CoatingsPrimers

Product specifications

Model NO.
FD-H001
Main Raw Material
Epoxy
Method
Spray
Level
Primer
Drying Method
Air Drying
Substrate
Steel
Components
Film Forming Matter
Formation Mechanism
Conversion Type
Luster
Matt
Weight
20kg/Barrel
Construction Method
High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness
Wet Film:80um Dry Film: 40um
After Sales Service
5 Years
Transport Package
Barrel Package in Pallet
Specification
35*30
Trademark
Signal
Origin
Dongying China
HS Code
3208100000
Production Capacity
50000ton/Year
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg
Lead Time
7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components
Two-component
Color
Grey
Proportion
About 2.40
Dry Time
23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio
10:1
Coating thickness
Wet film:80um Dry film: 40um
Construction methord
High pressure airless spray, air spray, brush, roller
Shelf life
12 months

Packaging & shipping

Transport Package
Barrel Package in Pallet
Specification
35*30
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg

Product description

Product Description

Product Name: High-Performance Epoxy Zinc Primer: Corrosion Protection for Chemical Facilities
FD-H001 High-Performance Epoxy Zinc Primer: Corrosion Protection for Chemical Facilities
1. Introduction:

Epoxyzinc-richprimerisatwo-componentcoatingwithepoxy resinasthebasematerial, enriched with phosphorironpowder,rust-proofpigment,etc., and skillfully cured by polyamide.It ismeticulously packed by dual componentsAand B.Characteristics:Unmatched highshielding properties, exceptionalanti-rustfeatures, robustadhesion, and remarkable oilandwaterresistance.
Number of components Two-component
Color Grey
Proportion About 2.40
Dry Time 23±2°C   Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio 10:1
Coating thickness Wet film:80um   Dry film: 40um
Construction methord High pressure airless spray, air spray, brush, roller
Shelf life 12 months

2. Surface treatment:
The steel surface is expertly shot blasted or sand blasted to achieve Sa2.5 level, or manually rust-removed to attain St3 level.

3. Construction conditions:
Ensure the substrate temperature is consistently 3°C above the dew point, with relative humidity maintained below 85%, and wind force not exceeding level 3. Construction should pause if the substrate temperature falls below 5°C as the epoxy resin and curing agent will halt reaction. Avoid construction during rainy, foggy, windy, and sandy conditions, as well as during condensation in the morning and evening for outdoor projects.

4. Notes:
1. Prior to application, mechanized stirring is essential to blend component A thoroughly, followed by uniform mixing with component B.
2. Conduct regular stirring during the coating process to prevent sedimentation, which could disrupt the powder to liquid ratio and compromise the paint film's quality.
3. We recommend a dry film thickness of at least 70μm, ensuring the application of 1 to 2 coats for optimal performance.
4. Post-mixing, utilize the two-component paint within 5 hours to maintain premium coating quality.
5. Securely cover the curing agent promptly after use and consume it as soon as possible to prevent unwanted reactions with atmospheric water vapor.
