FD-H001 Industrial Epoxy Primer Coating

Name: FD-H001 Industrial Epoxy Primer Coating
SKU: MIC-OfbRlkcCLopv

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $2-10 / kg

Quantity	Reference price
100-999 kg	USD 10.00 / kg
1,000-999,999 kg	USD 6.00 / kg
1,000,000+ kg	USD 2.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings Primers

Product specifications

Model NO.: FD-H001
Main Raw Material: Epoxy
Method: Spray
Level: Primer
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Luster: Matt
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:80um Dry Film: 40um
After Sales Service: 5 Years
Transport Package: Barrel Package in Pallet
Specification: 35*30
Trademark: signal
Origin: Dongying China
HS Code: 3208100000
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Lead Time: 7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components: Two-component
Color: Grey
Proportion: About 2.40
Dry Time: 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio: 10:1
Coating thickness: Wet film:80um Dry film: 40um
Construction methord: High pressure airless spray, air spray, brush, roller
Shelf life: 12 months

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

Product Description

Product Name: Factory Price Double Component Epoxy Anti-Corrosive Primer Coating

1. Introduction:

Epoxyzinc_-richprimerisatwo_-componentcoatingwithepoxy resinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Highshielding property, superioranti-rustproperty, strongadhesion, and good oilandwaterresistance.

Number of components	Two-component
Color	Grey
Proportion	About 2.40
Dry Time	23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio	10:1
Coating thickness	Wet film:80um Dry film: 40um
Construction methord	High pressure airless spray, air spray, brush, roller
Shelf life	12 months

2. Surface Treatment:
The steel surface is meticulously shot blasted or sand blasted to the Sa2.5 level, or manually rust-removed to the St3 level, ensuring a perfect base for coating.

3. Construction Conditions:
The substrate temperature must always be 3°C above the dew point, with relative humidity maintained below 85%, and wind force kept at or below level 3. If the substrate temperature falls below 5°C, the epoxy resin and curing agent will cease reacting, pausing construction. Avoid rainy, foggy, windy, or sandy conditions, and steer clear of morning and evening condensation for outdoor application.

4. Notes:
1. Prior to application, thoroughly mix component A using mechanical stirring, and subsequently blend it well with component B.
2. Ensure periodic stirring throughout the coating process to prevent sedimentation, which could disrupt the powder-to-liquid ratio, affecting the quality of the final paint film.
3. It is advised that the dry film thickness should meet or exceed 70μm, with 1 to 2 coats applied to achieve this.
4. Once mixed, the two-component paint should ideally be used within 5 hours to ensure optimal coating quality.
5. Once the curing agent is depleted, seal the container tightly and utilize it promptly to prevent losses from reactions with moisture in the air.
