Model: FD-H001

FD-H001 Matt Epoxy Paint Primer for Air Spray and Brush Techniques

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $4-10 / kg

QuantityReference price
100-9,999 kgUSD 10.00 / kg
10,000-999,999 kgUSD 8.00 / kg
1,000,000+ kgUSD 4.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

Product specifications

Model NO.
FD-H001
Main Raw Material
Epoxy
Method
Spray
Level
Primer
Drying Method
Air Drying
Substrate
Steel
Components
Film Forming Matter
Formation Mechanism
Conversion Type
Luster
Matt
Weight
20kg/Barrel
Construction Method
High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness
Wet Film:80um Dry Film: 40um
After Sales Service
5 Years
Transport Package
Barrel Package in Pallet
Specification
35*30
Trademark
signal
Origin
Dongying China
HS Code
3208100000
Production Capacity
50000ton/Year
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg
Lead Time
7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components
Two-component
Color
Grey
Proportion
About 2.40
Dry Time
23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio
10:1
Coating thickness
Wet film:80um Dry film: 40um
Construction methord
High pressure airless spray, air spray, brush, roller
Shelf life
12 months

Packaging & shipping

Transport Package
Barrel Package in Pallet
Specification
35*30
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg

Product description

Product Description

Product Name: Steel Structure Anti-Corrosion Epoxy Zinc Rich Primer Paint

1.Introduction:

Epoxyzinc-richprimerisatwo-componentcoatingwithepoxy resinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Boasting highshielding properties, exceptionalanti-rustqualities, robustadhesion, and outstandingoil andwaterresistance.
Number of components Two-component
Color Grey
Proportion About 2.40
Dry Time 23±2°C   Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio 10:1
Coating thickness Wet film:80um   Dry film: 40um
Construction methord High pressure airless spray, air spray, brush, roller
Shelf life 12 months

2.Surface treatment:
The steel surface is meticulously shot blasted or sand blasted to a pristine Sa2.5 level, or manually rust-removed to a refined St3 level.

3.Construction conditions:
Ensure the substrate temperature is a minimum of 3°C above the dew point with relative humidity under 85%, and wind force below level 3. If the substrate temperature drops below 5°C, halt construction as the epoxy resin and curing agent cease to react. Steer clear of construction during inclement weather conditions such as rain, fog, high winds, or sandstorms, and avoid times of condensation in mornings and evenings during outdoor applications.

4.Notes:
1. Prior to use, thoroughly mix component A using mechanical stirring, then blend evenly with component B.
2. Maintain regular stirring during the coating process to prevent sedimentation, which can lead to an imbalance in the powder-to-liquid ratio and compromise the quality of the paint film.
3. It is advised that the dry film thickness should be maintained at ≥70μm, with 1 to 2 coats being applied.
4. Post-mixing, ensure the two-component paint is utilized within 5 hours to maintain optimal coating quality.
5. Once the curing agent is depleted, securely cover and use promptly to prevent reactions with atmospheric water vapor that could lead to material loss.
