FD-H001 Matt Epoxy Paint Primer for High Pressure and Brush Use

Name: FD-H001 Matt Epoxy Paint Primer for High Pressure and Brush Use
SKU: MIC-sTDRCPKAAMpw

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $4-10 / kg

Quantity	Reference price
100-9,999 kg	USD 10.00 / kg
10,000-999,999 kg	USD 8.00 / kg
1,000,000+ kg	USD 4.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings Primers

Product specifications

Model NO.: FD-H001
Main Raw Material: Epoxy
Method: Spray
Level: Primer
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Luster: Matt
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:80um Dry Film: 40um
After Sales Service: 5 Years
Transport Package: Barrel Package in Pallet
Specification: 35*30
Trademark: signal
Origin: Dongying China
HS Code: 3208100000
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Lead Time: 7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components: Two-component
Color: Grey
Proportion: About 2.40
Dry Time: 23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio: 10:1
Coating thickness: Wet film:80um Dry film: 40um
Construction methord: High pressure airless spray, air spray, brush, roller
Shelf life: 12 months

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

Product Description

Product Name: Steel Structure Anti-Corrosion Epoxy Zinc Rich Primer Paint

1.Introduction:

Epoxyzinc_-richprimerisatwo_-componentcoatingwithepoxyresinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Boasting a highshielding property, this primer offers superioranti-rustcapabilities, ensuring strongadhesion along with excellent oilandwaterresistance.

Number of components	Two-component
Color	Grey
Proportion	About 2.40
Dry Time	23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio	10:1
Coating thickness	Wet film:80um Dry film: 40um
Construction methord	High pressure airless spray, air spray, brush, roller
Shelf life	12 months

2.Surface treatment:
The steel surface should be meticulously prepared, utilizing shot blasting or sand blasting to achieve Sa2.5 level, or manually rust-removed to St3 level to ensure optimal adherence.

3.Construction conditions:
Ensure that the substrate temperature is consistently 3°C higher than the dew point, with relative humidity maintained at less than 85%, and wind force not exceeding level 3. Notably, when the substrate temperature falls below 5°C, the epoxy resin and curing agent halt their reaction, necessitating a pause in construction activities. Avoid conducting work on rainy, foggy, windy, or sandy days and steer clear of morning and evening condensation for any outdoor projects.

4.Notes:
1. Prior to application, thoroughly mix component A using mechanical stirring until uniform, then blend it evenly with component B.
2. It is vital to regularly stir the mixture during the coating process to prevent sedimentation; failure to do so can disrupt the balance of powder to liquid ratio, compromising the quality of the paint film.
3. For optimal coverage, it is recommended to achieve a dry film thickness of at least 70μm, with the application of 1 to 2 coats.
4. Once mixed, the two-component paint should ideally be used within 5 hours to maintain the coating's integrity. Exceeding this time frame could degrade the quality.
5. After utilization, tightly cover the curing agent to avoid any undesirable reactions with moisture in the air and to prevent wastage.
