Model: FD-H001

FD-H001 Matt Epoxy Primer Coating - Ideal for Airless Spray Techniques

FD-H001 two-component epoxy primer for steel substrates.

Reference price (FOB)

US $4-10 / kg

QuantityReference price
100-9,999 kgUSD 10.00 / kg
10,000-999,999 kgUSD 8.00 / kg
1,000,000+ kgUSD 4.00 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

Product specifications

Model NO.
FD-H001
Main Raw Material
Epoxy
Method
Spray
Level
Primer
Drying Method
Air Drying
Substrate
Steel
Components
Film Forming Matter
Formation Mechanism
Conversion Type
Luster
Matt
Weight
20kg/Barrel
Construction Method
High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness
Wet Film:80um Dry Film: 40um
After Sales Service
5 Years
Transport Package
Barrel Package in Pallet
Specification
35*30
Trademark
signal
Origin
Dongying China
HS Code
3208100000
Production Capacity
50000ton/Year
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg
Lead Time
7 days (1 - 1000 kg) To be negotiated ( > 1000 kg)
Number of components
Two-component
Color
Grey
Proportion
About 2.40
Dry Time
23±2°C Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio
10:1
Coating thickness
Wet film:80um Dry film: 40um
Construction methord
High pressure airless spray, air spray, brush, roller
Shelf life
12 months

Packaging & shipping

Transport Package
Barrel Package in Pallet
Specification
35*30
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg

Product description

Product Description

Product Name: Hot Sales High-Performance Anti Rust Zinc Epoxy Primer for Steel Buildings

FD-H001 Matt Epoxy Primer Coating - Ideal for Airless Spray Techniques
1. Introduction:

Epoxyzinc-richprimerisatwo-componentcoatingwithepoxy resinasthebasematerial, phosphorironpowder,rust-proofpigment,etc., and cured by polyamide.It ispacked by dual componentsAand B.Characteristics:Exemplaryshielding properties, exceptionalanti-rustcapabilities, robustadhesion, and impressive oilandwaterresistance.
Number of components Two-component
Color Grey
Proportion About 2.40
Dry Time 23±2°C   Surface dry time ≤30min, Through dry time ≤24h, Fully cured 7 days
Mixing ratio 10:1
Coating thickness Wet film:80um   Dry film: 40um
Construction methord High pressure airless spray, air spray, brush, roller
Shelf life 12 months

2. Surface treatment:
The steel surface undergoes shot blasting or sand blasting to achieve Sa2.5 level perfection, or manual rust removal to attain St3 level sophistication.

3. Construction conditions:
Ensure the substrate temperature is at least 3°C above the dew point, with relative humidity remaining under 85%, and wind force not exceeding level 3. Avoid construction when the temperature falls below 5°C, as the epoxy resin and curing agent cease reaction. Refrain from outdoor construction during rainy, foggy, windy, and sandy conditions, as well as during morning and evening condensation.

4. Notes:
1. Prior to use, employ mechanical stirring to thoroughly mix component A, and subsequently blend it uniformly with component B.
2. Maintain regular stirring during the coating process to avert sedimentation, which can disrupt the powder to liquid ratio and compromise the paint film's quality.
3. Aim for a minimum dry film thickness of ≥70μm, with the completion of 1 to 2 coats.
4. Post-mixing, utilize the two-component paint within a 5-hour window to ensure optimum coating quality.
5. After utilizing the curing agent, seal it tightly and deplete it promptly to avoid losses from reactions with atmospheric water vapor.
