FD-H002 Matt Two-Component Epoxy Iron Oxide Red Anticorrosive Primer Coating

Name: FD-H002 Matt Two-Component Epoxy Iron Oxide Red Anticorrosive Primer Coating
SKU: MIC-qthYIMwlhTRc

FD-H002 two-component epoxy primer for steel substrates. Supplied in liquid form.

Reference price (FOB)

US $4-4.5 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings Primers

Product specifications

Model NO.: FD-H002
Color: Iron Oxide Red
Appearance: Liquid
Main Raw Material: Epoxy
Method: Spray
Level: Primer
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Luster: Matt
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:80um Dry Film: 40um
After Sales Service: 5 Years
Component: Two-Component
Trademark: Singal
Transport Package: Barrel Package in Pallet
Specification: 35*30
Origin: China
HS Code: 3208100000
Customization: Available
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Number of components: Two-component
Theoretical Coverage Rate: 190 g/m², 6.32 m²/L (calculated at 40 μm dry film thickness, excluding wastage)
Proportion: About 1.50
Dry Time: 23±2°C Surface dry time ≤30min, Through dry time ≤24h
Fully cured: 7 days
Flash Point: 45 ºC
Shelf life: 12 months
Mixing Ratio: Component A (Base Paint) : Component B (Curing Agent) = 4:1
Maturation Time: 23 ± 2°C:0.5-1h
Pot Life: 23 ± 2°C: 5h
Application Methods: Airless spraying, conventional air spraying, brushing, rolling
Thinner: X-300 Thinner
Tool Cleaning: X-300 Thinner
Film Thickness: Wet film: 160 μm Dry film: 40 μm

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

FD-H002
Premium Matt Two-component Epoxy Iron Oxide Red Anticorrosive Primer Coating

Product Description:

Two-component coating composed of epoxy resin, iron oxide red, anti-corrosive pigments, additives, and thinners, packaged in Component A and Component B. This product features rapid drying speed, excellent physical and mechanical properties of the film, and superior anti-corrosive performance.

Application Fields:
Widely used for anti-corrosion protection of engineering machinery and steel structures.

Physical Parameter

Number of components	Two-component
Color	Iron Oxide Red
Theoretical Coverage Rate	190 g/m², 6.32 m²/L (calculated at 40 μm dry film thickness, excluding wastage)
Proportion	About 1.50
Dry Time	23±2°C Surface dry time ≤30min, Through dry time ≤24h
Fully cured	7 days
Flash Point	45 ºC
Shelf life	12 months

Construction Instruction

Mixing Ratio	Component A (Base Paint) : Component B (Curing Agent) = 4:1
Maturation Time	23 ± 2°C:0.5-1h
Pot Life	23 ± 2°C: 5h
Application Methods	Airless spraying, conventional air spraying, brushing, rolling
Thinner	X-300 Thinner
Tool Cleaning	X-300 Thinner
Film Thickness	Wet film: 160 μm Dry film: 40 μm

	Airless Spraying	Conventional Air Spraying	Manual Rolling and Brushing
Maximum Thinner Addition	10%	20%	15%
Nozzle Orifice	0.4-0.5mm	2.0-2.5mm
Discharge Pressure	15-20MPa	0.3-0.6Mpa

Recoating Interval

Ambient Temperature	5ºC	20ºC	30ºC
Interval	24h	16h	8h

Surface treatment:
The steel surface is shot blasted or sand blasted to Sa2.5 level, or manually rust-removed to St3 level.

Compatible Coatings

Epoxy resin coating,Epoxy asphalt coating etc.

Construction conditions:
Substrate temperature must exceed the dew point by at least 3°C, with relative humidity <85% and wind speed ≤ Level 3.Outdoor applications shall avoid rainy, foggy, or dusty conditions, as well as morning/evening dew formation.Under normal circumstances, the coated surface should not be exposed to rain within 16 hours after application.

Notes:

1.For difficult-to-coat areas of steel such as corners, dents, and weld seams, to prevent coating defects like bubbles and pinholes from forming in these areas, first apply a local brush coat with a brush, then proceed with large-area painting.
2.If multiple coats are required to increase the film thickness, after the completion of the previous coat and before applying the next coat, the previous coat should be inspected. Inspection items include dryness and thickness, as well as the presence of bubbles, pinholes, wrinkles, etc., so that timely adjustments and treatments can be made during the next coating process.

Storage:

1.The product must be stored in tightly sealed containers in a well-ventilated, dry area away from direct sunlight. The recommended storage temperature range is 0-35°C.
2.The product shelf life is 12 months from the date of manufacture. Beyond this period, the product may be retested according to specifications. If compliant, it may continue to be used.

Safety:

1.Use only in well-ventilated areas. Avoid inhalation of mists or vapors. Prevent contact with skin and eyes. In case of eye contact, rinse thoroughly with plenty of water and seek immediate medical attention.
2.When applying in confined or poorly ventilated spaces, mandatory forced ventilation and full protective equipment (respirator, gloves, goggles) must be used.
