FM-F004 Polysiloxane Modified Resin Base for Two-Component Polysiloxane Topcoat

Name: FM-F004 Polysiloxane Modified Resin Base for Two-Component Polysiloxane Topcoat
SKU: MIC-UadYrcjSEkRF

FM-F004 two-component polysiloxane topcoat for steel substrates.

Reference price (FOB)

US $2.5-6.5 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

CategoriesAnti-Corrosion Coatings Topcoats

Product specifications

Model NO.: FM-F004
Main Raw Material: Polysiloxane
Method: Spray
Level: Finish Coat
Drying Method: Air Drying
Substrate: Steel
Components: Film Forming Matter
Formation Mechanism: Conversion Type
Weight: 20kg/Barrel
Construction Method: High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness: Wet Film:125um Dry Film: 70um
After Sales Service: 5 Years
Component: Two-Component
Transport Package: Barrel Package in Pallet
Specification: 35*30
Trademark: Singal
Origin: China
HS Code: 3208100000
Production Capacity: 50000ton/Year
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg
Number of components: Two-component
Color: Various Colors
Viscosity (Coating No. 4 Cup): ≥25S
Appearance of paint film: Smooth and Even
Proportion: 1.9kg/L
Dry Time: 23±2°C Surface dry time ≤1h, Through dry time ≤24h
Fully cured: 7 days
Flash Point: 28 ºC
Shelf life: 12 months
Mixing Ratio: Component A (Base Paint) : Component B (Curing Agent) = 5:1
Maturation Time: 23 ± 2°C:20 minutes
Pot Life: 23 ± 2°C:5 h
Application Methods: Airless spraying, conventional air spraying,Brushing and Rolling
Thinner: X-500 Thinner
Tool Cleaning: X-500 Thinner
Film Thickness: Wet film: 125 μm Dry film: 70 μm

Packaging & shipping

Transport Package: Barrel Package in Pallet
Specification: 35*30
Package Size: 30.00cm * 30.00cm * 35.00cm
Package Gross Weight: 20.000kg

Product description

FM-F004
Advanced Polysiloxane Modified Resin Base for Two-Component Polysiloxane Topcoat

Product Description:

This two-component coating is formulated with a high-grade polysiloxane-modified resin binder, supplemented by imported titanium dioxide, additives, solvents, and other components. The resulting paint film exhibits excellent physical and mechanical properties, as well as outstanding corrosion resistance, humidity and heat resistance, salt spray resistance, gloss retention, color retention, and exceptionally long-term weatherability.

Application Fields:
It is suitable for the protection and decoration of various metal and non-metal structures with long-term anti-corrosion requirements, including chemical facilities, bridges, docks, decorative components of buildings, municipal facilities, etc.

Physical Parameter

Number of components	Two-component
Color	Various Colors
Viscosity (Coating No. 4 Cup)	≥25S
Appearance of paint film	Smooth and Even
Proportion	1.9kg/L
Dry Time	23±2°C Surface dry time ≤1h, Through dry time ≤24h
Fully cured	7 days
Flash Point	28 ºC
Shelf life	12 months

Construction Instruction

Mixing Ratio	Component A (Base Paint) : Component B (Curing Agent) = 5:1
Maturation Time	23 ± 2°C:20 minutes
Pot Life	23 ± 2°C:5 h
Application Methods	Airless spraying, conventional air spraying,Brushing and Rolling
Thinner	X-500 Thinner
Tool Cleaning	X-500 Thinner
Film Thickness	Wet film: 125 μm Dry film: 70 μm

	Airless Spraying	Conventional Air Spraying	Manual Rolling and Brushing
Maximum Thinner Addition	5%	15%	Use a short-nap roller to avoid the formation of bubbles.
Nozzle Orifice	0.4-0.5mm	2.0-2.5mm
Discharge Pressure	15-20MPa	0.3-0.4Mpa

Recoat Interval:

Ambient Temperature	5ºC	10ºC	23ºC	40ºC
Minimum Interval	29h	237h	12h	4h
Maximum Interval	15d	10d	5d	3d

Surface treatment:
To ensure long-lasting adhesion of the coating, all surfaces must be clean, dry, and coated with a sound and compatible primer (in compliance with ISO 12944-4, Clause 46.1). If the previous coating has been contaminated, appropriate methods should be selected to remove grease and dust; the diluent of this paint can also be used for wiping clean.

Compatible Coatings
1.Epoxy zinc-rich primer + epoxy mica iron oxide intermediate coat + polysiloxane topcoat.
2.Inorganic zinc-rich primer + epoxy sealer coat + epoxy mica iron oxide intermediate coat + polysiloxane topcoat.

Construction conditions:
Substrate temperature must exceed the dew point by at least 3°C, with relative humidity <85% and wind speed ≤ Level 3.Outdoor applications shall avoid rainy, foggy, or dusty conditions, as well as morning/evening dew formation.Under normal circumstances, the coated surface should not be exposed to rain within 16 hours after application.

Notes:
1.During construction, the paint should be prepared according to the required amount, and the mixed paint must be used up within 5 hours to prevent gelation and waste due to prolonged storage.
2.The tools used for construction should be kept dry and clean, and no impurities such as moisture or grease should be mixed into the coating.

Storage:
1.The product must be stored in tightly sealed containers in a well-ventilated, dry area away from direct sunlight. The recommended storage temperature range is 0-35°C.
2.The product shelf life is 12 months from the date of manufacture. Beyond this period, the product may be retested according to specifications. If compliant, it may continue to be used.

Safety:
1.Use only in well-ventilated areas. Avoid inhalation of mists or vapors. Prevent contact with skin and eyes. In case of eye contact, rinse thoroughly with plenty of water and seek immediate medical attention.
2.When applying in confined or poorly ventilated spaces, mandatory forced ventilation and full protective equipment (respirator, gloves, goggles) must be used.
