Model: FM-S001

FM-S001 Two-Component Various Colors High Gloss Acrylic Polyurethane Topcoat Anticorrosive Coating

FM-S001 two-component acrylic topcoat for steel substrates.

Reference price (FOB)

US $5.4-6 / kg

Minimum order: 100 kg

Confirm the specification, quantity and shipping terms for your quotation.

Request a Quote

Product specifications

Model NO.
FM-S001
Main Raw Material
Acrylic
Method
Spray
Level
Finish Coat
Drying Method
Air Drying
Substrate
Steel
Components
Film Forming Matter
Formation Mechanism
Conversion Type
Luster
High Gloss
Weight
20kg/Barrel
Construction Method
High Pressure Airless Spray, Air Spray, Brush, Rol
Coating Thickness
Wet Film:170um Dry Film: 75um
After Sales Service
5 Years
Component
Two-Component
Transport Package
Barrel Package in Pallet
Specification
35*30
Trademark
Singal
Origin
China
HS Code
3208100000
Production Capacity
50000ton/Year
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg
Number of components
Two-component
Color
Various Colors
Gloss
High Gloss
Theoretical Coverage Rate
220 g/m² (calculated at 75 μm dry film thickness, excluding wastage)
Proportion
About 1.30
Dry Time
23±2°C Surface dry time ≤2h, Through dry time ≤24h
Fully cured
7 days
Flash Point
27 ºC
Shelf life
12 months
Mixing Ratio
Component A (Base Paint) : Component B (Curing Agent) = 3:1
Maturation Time
23 ± 2°C:20 minutes
Pot Life
23 ± 2°C: 5 h
Application Methods
Airless spraying, conventional air spraying, brushing, rolling
Thinner
X-500 Thinner
Tool Cleaning
X-500 Thinner
Film Thickness
Wet film: 175 μm Dry film: 75 μm

Packaging & shipping

Transport Package
Barrel Package in Pallet
Specification
35*30
Package Size
30.00cm * 30.00cm * 35.00cm
Package Gross Weight
20.000kg

Product description



FM-S001 Two-Component Various Colors High Gloss Acrylic Polyurethane Topcoat Anticorrosive CoatingFM-S001
Premium Two-component Various Colors High Gloss Acrylic Polyurethane Topcoat Anticorrosive Coating



Product Description:

This two-component ambient-curing coating is formulated with hydroxy acrylic resin and aliphatic polyurethane curing agent as the base materials, and trimerized isocyanate as the curing agent. It also incorporates pigments, fillers, solvents, and additives. The resulting paint film is tough, exhibits excellent fullness and high gloss, providing superior protective and decorative effects. Additionally, it demonstrates favorable physical and mechanical properties, as well as resistance to humidity and heat, salt spray, color and gloss retention, and weatherability.




Application Fields:
It is suitable for use as an anti-corrosive topcoat on the surfaces of ships, bridges, engineering machinery, and large and medium-sized steel structures.

FM-S001 Two-Component Various Colors High Gloss Acrylic Polyurethane Topcoat Anticorrosive Coating



Physical Parameter

Number of components Two-component
Color Various Colors
Gloss High Gloss
Theoretical Coverage Rate 220 g/m² (calculated at 75 μm dry film thickness, excluding wastage)
Proportion About 1.30
Dry Time 23±2°C   Surface dry time ≤2h, Through dry time ≤24h
Fully cured 7 days
Flash Point 27 ºC
Shelf life 12 months


Construction Instruction

Mixing Ratio Component A (Base Paint) : Component B (Curing Agent) = 3:1
Maturation Time 23 ± 2°C:20 minutes
Pot Life 23 ± 2°C: 5 h
Application Methods Airless spraying, conventional air spraying, brushing, rolling
Thinner X-500 Thinner
Tool Cleaning X-500 Thinner
Film Thickness Wet film: 175 μm    Dry film: 75 μm



  Airless Spraying Conventional Air Spraying Manual Rolling and Brushing
Maximum Thinner Addition 5% 15%
Nozzle Orifice 0.4-0.5mm 2.0-2.5mm
Discharge Pressure 15-20MPa 0.3-0.4Mpa


Recoating Interval

Ambient Temperature 10ºC 20ºC 30ºC
Min 24h 8h 6h
Max Unlimited


Surface treatment:

If the previous coating layer has been contaminated, appropriate methods should be selected to remove grease and dust. Alternatively, the diluent of this paint can also be used for wiping clean.



Compatible Coatings

Epoxy zinc-rich primer, inorganic zinc-rich primer, epoxy micaceous iron oxide antirust paint, etc.



Construction conditions:
Substrate temperature must exceed the dew point by at least 3°C, with relative humidity <85% and wind speed ≤ Level 3.Outdoor applications shall avoid rainy, foggy, or dusty conditions, as well as morning/evening dew formation.Under normal circumstances, the coated surface should not be exposed to rain within 16 hours after application.



Notes:

1.During construction, the paint should be prepared according to the required amount, and the mixed paint must be used up within 5 hours to prevent gelation and waste due to prolonged storage.
2.The tools used for construction should be kept dry and clean, and no impurities such as water, banana oil, alcohol-based solvents, or gasoline should be mixed into the paint.
3.After use, the curing agent container must be tightly sealed and used up as soon as possible to prevent losses caused by reactions with moisture or other substances in the air.



Storage:

1.The product must be stored in tightly sealed containers in a well-ventilated, dry area away from direct sunlight. The recommended storage temperature range is 0-35°C.
2.The product shelf life is 12 months from the date of manufacture. Beyond this period, the product may be retested according to specifications. If compliant, it may continue to be used.



Safety:

1.Use only in well-ventilated areas. Avoid inhalation of mists or vapors. Prevent contact with skin and eyes. In case of eye contact, rinse thoroughly with plenty of water and seek immediate medical attention.
2.When applying in confined or poorly ventilated spaces, mandatory forced ventilation and full protective equipment (respirator, gloves, goggles) must be used.
